2010 Chevrolet Camaro SS

Brakes

Brake Type

Pwr

Brake ABS System

4-wheel

Brake ABS System (Second Line)

N/A

Disc – Front (Yes or )

Yes

Disc – Rear (Yes or )

Yes

Front Brake Rotor Diam x Thickness

12.64 x 1.18 in

Rear Brake Rotor Diam x Thickness

12.4 x 0.9 in

Cargo Area Dimensions

Trunk Volume

11.3 ft³

Cooling System

Total Cooling System Capacity

N/A qts

Electrical

Cold Cranking Amps @ 0° F (Primary)

N/A

Maximum Alternator Capacity (amps)

150

Engine

Engine Order Code

LLT

Engine Type

Gas V6

Displacement

3.6L/220

Fuel System

SIDI

SAE Net Horsepower @ RPM

304 @ 6400

SAE Net Torque @ RPM

273 @ 5200

Exterior Dimensions

Wheelbase

112.3 in

Length, Overall

190.4 in

Width, Max w/o mirrors

75.5 in

Height, Overall

54.2 in

Track Width, Front

63.7 in

Track Width, Rear

64.1 in

Min Ground Clearance

N/A in

Liftover Height

N/A in

Fuel Tank

Fuel Tank Capacity, Approx

19 gal

Aux Fuel Tank Capacity, Approx

N/A gal

Interior Dimensions

Passenger Capacity

4

Passenger Volume

N/A ft³

Front Head Room

37.4 in

Front Leg Room

42.4 in

Front Shoulder Room

56.9 in

Front Hip Room

N/A in

Second Head Room

35.3 in

Second Leg Room

29.9 in

Second Shoulder Room

42.5 in

Second Hip Room

N/A in

Mileage

EPA Fuel Economy Est – Hwy

29 MPG

Cruising Range – City

323.00 mi

EPA Fuel Economy Est – City

17 MPG

Fuel Economy Est-Combined

21 MPG

Cruising Range – Hwy

551.00 mi

Steering

Steering Type

Pwr

Steering Ratio (:1), Overall

16.1

Lock to Lock Turns (Steering)

2.5

Turning Diameter – Curb to Curb

37.7 ft

Turning Diameter – Wall to Wall

N/A ft

Suspension

Suspension Type – Front

Multi-Link Strut

Suspension Type – Rear

4.5-Link Independent

Suspension Type – Front (Cont.)

Double Ball Joint

Shock Absorber Diameter – Front

N/A mm

Shock Absorber Diameter – Rear

N/A mm

Stabilizer Bar Diameter – Front

N/A in

Stabilizer Bar Diameter – Rear

N/A in

Tires

Front Tire Order Code

QAM

Rear Tire Order Code

QAM

Front Tire Size

P245/55R18

Rear Tire Size

P245/55R18

Trailering

Transmission

Drivetrain

Rear wheel drive

Trans Order Code

MN6

Trans Type

6

Trans Description Cont.

Manual

First Gear Ratio (:1)

4.48

Second Gear Ratio (:1)

2.58

Third Gear Ratio (:1)

1.63

Fourth Gear Ratio (:1)

1.19

Fifth Gear Ratio (:1)

1.00

Sixth Gear Ratio (:1)

0.75

Reverse Ratio (:1)

3.67

Clutch Size

N/A in

Final Drive Axle Ratio (:1)

3.27

Vehicle

EPA Classification

Compact

EPA Greenhouse Gas Score

5

Weight Information

Base Curb Weight

3780 lbs

Wheels

Front Wheel Size

18 x 7.5 in

Rear Wheel Size

18 x 7.5 in

Front Wheel Material

Steel

Rear Wheel Material

Steel

ENTERTAINMENT

Audio system, AM/FM stereo with CD-ROM and MP3 playback music navigator, Graphic Information Display (GID) and auxiliary input jack, includes outside temperature display

Audio system feature 6-speaker system

XM Radio is standard on more than 50 2010 GM models, including three trial months of service. XM turns your world on with commercial-free music channels for virtually every music genre, all in amazing digital quality sound. Turn on your favorite sports, the biggest names in News, Talk and Comedy, family programming, exclusive concerts and original music series, wherever you go from coast to coast. Everything worth listening to is now on XM (XM service available only in the 48 contiguous United States and the District of Columbia. XM Radio subscription required and sold separately after trial period. Fees, taxes, and a one-time re-activation fee, may apply. Subscriptions governed by XM Customer Agreement available at xmradio.com. All fees and programming subject to change. Family programming Packages are available.)

Antenna, integral rear window

Antenna, OnStar and XM Radio fin-type (Located on roof.)

EXTERIOR

Wheels, 18″ (45.7 cm) heritage steel

Tires, P245/55R18 touring, blackwall, all-season

Tire sealant and inflator kit in place of spare tire

Molding, Black roof ditch

Fascias, front and rear body-color with front grille and rear diffuser

Moldings, body-color lower rocker

Hood blanket with debossed Chevrolet bowtie

Headlamps, halogen composite with automatic exterior lamp control

Mirrors, outside power-adjustable body-color

Wipers, front intermittent

Door handles, body-color

INTERIOR

Seat adjuster, driver 4-way manual (fore/aft, up/down) with power recliner

Seat adjuster, front passenger 2-way manual (fore/aft) with power recliner

Console, floor, with armrest

Dead pedal, driver

Steering wheel, 3-spoke, urethane

Steering column, manual rake and telescopic

Instrumentation, analog with Driver Information Center display, includes speedometer, tachometer, fuel gauge and engine temperature gauge

Compass, located in Driver Information Center

Door locks, power programmable with lockout protection

Remote Keyless Entry

Windows, power with driver and passenger Express-Down/Up

Cruise control, electronic with set and resume speed, steering wheel mounted

Trunk release, remote, located on driver-side

Theft-deterrent system, PASS-Key III

Air conditioning, single-zone manual

Air filtration system with pollen filter

Defogger, rear-window, electric

Glovebox, lockable

Power outlets, 2 auxiliary 1 located in center console storage area and 1 located at front of center console

Cup holders, 2 front

Map pockets, front doors

Mirror, inside rearview manual day/night

Visors, driver and front passenger vanity mirrors, covered

Lighting, front reading lamps

Lighting, interior dome with illuminated entry and theater dimming

Coat hooks, driver- and passenger-side rear

Shift knob, urethane

MECHANICAL

Engine, 3.6L Variable Valve Timing V6 with SIDI (Spark Ignition Direct Injection) (304 hp [226.7 kW] @ 6400 rpm, 273 lb-ft of torque [368.6 N-m] @ 5200 rpm)

Transmission, 6-speed manual

Axle, 3.27 ratio

Rear wheel drive

Alternator, 150 amps

Battery, maintenance-free with rundown protection and retained accessory power

Suspension, Sport

Steering, power, variable ratio

Brakes, 4-wheel antilock, 4-wheel disc (Single piston front brakes with super corner rear brakes.)

Exhaust, dual-outlet stainless-steel with polished tips

SAFETY

StabiliTrak, stability control system with traction control

Daytime Running Lamps

Air bags, dual-stage frontal, thorax side-impact for driver and front passenger and head curtain side-impact for front and rear outboard seating positions includes Passenger Sensing System (Always use safety belts and the correct child restraints for your child’s age and size. Even in vehicles equipped with air bags and the Passenger Sensing System, children are safer when properly secured in a rear seat. Never place a rear-facing infant restraint in the front seat of any vehicle equipped with an active frontal air bag. See the vehicle’s Owner’s Manual and child safety seat instructions for more safety information.)

OnStar, 1-year of Safe and Sound plan. Includes Automatic Crash Response, Emergency Services, Crisis Assist, Stolen Vehicle Assistance, Remote Door Unlock, Roadside Assistance, Remote Horn and Lights, Hands Free Calling, OnStar Vehicle Diagnostics, and Low Mileage Discount. (OnStar services require vehicle electrical system (including battery), wireless service and GPS satellite signals to be available and operating for features to function properly. OnStar acts as a link to existing emergency service providers. Vehicle Diagnostics capabilities vary by model. Remote door unlock success varies with conditions. Ability to locate stolen vehicles varies with conditions.

Safety belts, 3-point, all seating positions

Safety belt pretensioners driver and front passenger

LATCH system (Lower Anchors and Top tethers for CHildren) for child safety seats

Trunk emergency release handle

Tire Pressure Monitoring System
